MTS100 MTS Charging and Discharging Test System
- High voltage accuracy±0.05% of F.S.
- High current accuracy±0.05% of F.S.
- Discharge energy feedback;
- Fast current response < 5ms;
- Discharge energy recovery efficiency reaching 90%;
- High-speed data recording time 10ms;
- Channel parallel up to 2400A;
- Multiple safety protection for module;
- Integrated multifunction logger with thermostat/humidity chamber;
- Related Products
- Additional Information
MTS100 MTS Charging and Discharging Test System Overview
MTS100 is a professional charge/discharge test equipment developed for high current/high power performance testing. It is suitable for performance testing and evaluation of high-capacity Li-ion cells and Li-ion capacitors, cycle life veriﬁcation, and product model selection.
Adopted with the latest technique, MTS 100 features high energy conversion eﬃciency, high voltage and current accuracy, fast current dynamic response, multi-current range automatic staging, high power density, and high safety factor in actual use. The MTS100 is characterized by high energy conversion eﬃciency, high voltage and current accuracy, fast current dynamic response, automatic multi-current range current staging, high power density, and high safety factor.
High current cycle life test requires high energy conversion eﬃciency of the test equipment, thus MTS100 series products are designed with lower energy cost and at the same time less heat generation so that the internal system including the elements for accuracy control can work under a relatively low temperature to eﬀectively avoid temperature excursion of key elements’ parameters and short-ened service life caused by temperature variation.
High Eﬃciency of Energy Recovery
MTS100 feeds battery discharge power back to the AC grid instead of high energy consumption to reduce a large amount of waste heat generation and realize green energy manufacturing with low carbon emission. Reduced demand for power distribution leads to reduced operating electricity and air conditioning cost. Battery cell discharge is recycled to the regional grid, and the recycling eﬃciency can reach up to 90%. High eﬃciency brings higher power density, and thus the same laboratory conﬁguration occupies less space and lower operating costs.
Multi-current gear 300A/200A/50A or 100A/50A/30A
Automatically select appropriate current level in constant current mode
Multiple current output and measurement levels are available to cover high and low current test processes.
Automatically select the appropriate current level in constant voltage mode
Automatically switch current level in constant voltage mode without interrupting output to improve the current resolution and increase consistency of the cut-oﬀ judgment condition.
Quick dynamic response time
High-speed current response time <5ms. Fast current response to provide more ideal experimental conditions, reducing cumulative capacitance error and obtaining lower distorted data in rapidly changing dynamic tests.
Convenient human-machine interface
Centralized management of testing equipment and battery test data with real-time display of battery status (voltage, current, power, capacity, energy, etc.).
Various customized curves and curve comparison for users to analyze battery test data professionally.
Simulation of working conditions
Able to convert the actual electric vehicle operating conditions data into battery testing process to simulate operating conditions on the battery.
Testing plan edit
Various phases conbined (constant current charge/discharge, constant voltage charge/discharge, constant power charge/discharge, pulse, work condition simulation, DCIR, etc.) to set overall/single phase recording conditions and protection conditions for battery charge/discharge tests.
Battery test data exported in various forms of reports.
Coordination with surrounding decices
Peripheral devices (thermostat, water chiller, etc.) controlled in many forms through a gigabit switch based on TCP/IP network communication.
|Voltage Range||MTS100-120-300-6: Charge 0V～120V, Discharge 5V～120V;
MTS100-150-500-4: Charge 0V～150V, Discharge 5V～150V;
MTS100-200-200-4: Charge 0V～200V, Discharge 20V～200V;
PTS100-800-500-2: Charge 0V～800V, Discharge 20V～800V;
|Voltage accuracy||±0.05%F.S. @25℃±10℃|
|Current range||MTS100-120-300-6: -300A~300A;
|Current accuracy||±0.05%F.S. @25℃±10℃|
|Fastest sampling time of main channel||10ms|
|Current rise time||MTS100-120-300-6: ＜ 5ms;
MTS100-150-500-4: ＜ 5ms;
MTS100-200-200-4: ＜ 10ms;
PTS100-800-500-2: ＜ 10ms;
|Charge eﬃciency||MTS100-120-300-6: 93% (max);
MTS100-150-500-4: 93% (max);
MTS100-200-200-4: 93% (max);
PTS100-800-500-2: 96% (max);
|Discharge eﬃciency||MTS100-120-300-6: 90% (max);
MTS100-150-500-4: 90% (max);
MTS100-200-200-4: 90% (max);
PTS100-800-500-2: 93% (max);
|Auxiliary voltage protection channel||Accuracy ±1.5mV （25℃±10℃), sampling rate 10ms, -8V～8V, leakage current＜0.1uA, input impedance＞200MΩ, one for each main channel;|
|BMS connect||Load *.dbc conﬁg ﬁle into the software|
|Auxiliary temperature protection channel (NTC or thermocouple two options)||Accuracy ±0.5（25℃±20℃），-40℃～125℃, sampling rate 500ms, 4NTC temperature detection at most for each main channel;
Accuracy ±1（25℃±20℃)，-70℃～250℃, sampling rate 500ms,3K-type or T-type thermocouples for each main channel at most;
|Mechanical dimensions (W*H*D)mm||MTS100-120-300-6: 720*1900*750;
|Mechanical weight||MTS100-120-300-6: ＜500Kg;
MTS100-150-500-4: ＜ 500Kg;
MTS100-200-200-4: ＜ 1000Kg;
PTS100-800-500-2: ＜ 2400Kg;
