VH500 Series EtherCAT Type PLC

Product Features

1G CPU

Substantial increase in command processing speed over previous products for high speed and high precision motion control and stable process control.

Multi-level Network

• 1×RS 485 on the product for CANopen communication, 72 EtherCAT slaves max.
• Dual Ethernet ports for easy networking over levels.

Bus + Pulse Motion Control

• Up to 48 real axes for EtherCAT bus motion control, 64 real and virtual axes in total.
• 8×high-speed pulse input and output(200kHZ).

Self-developed Programming Soft

• ST in programming to write complex algorithms and logic.
• Offline debugging and online modification functions to reduce on-site debugging time.
• Function block encapsulation to quick apply the process algorithms.

48-Axis EtherCAT

48-axis high-speed bus control with sync movement for complex production. Fast and precise control for higher end-user benefits.

Simple wiring for lower design and labor cost and quicker maintenance.

Jerk ACC and DEC

Jerk value regulation for smoother ACC/DEC curve and less mechanical shock.

x-coordinat: Time

1st Y-coordinate: Speed

2nd Y-coordinate: Acceleration

3rd Y-coordinate: Acceleration change rate

• Change rate of ACC/DEC speed obtained directly from the ACC/DEC time without calculation.
• Change rate visualized in the smoothness of the ACC/DEC curves.

Advanced industrial Ethernet and distributed master/slave. Easy installation for faster information transfer cycle and faster communication and sync. Linear arc interpolation, cams and other modes available.

• Motion network bus EtherCAT with communication cycle as fast as 250us.
• Multi-axis commands such as e-gear and e-cam.
• Single-axis motion commands such as position, speed, and home.
• Main axis for encoder or virtual axis, real axis, external input, etc.
• Servo probe, high-speed counter probe, encoder probe available.
• Phase compensation, motion superposition, etc.

Programming Software
