ECH Series Brushless Coreless Motor
- High-speed.
- High-torque.
- Low-noise.
Catalogue
Contact support
EmailECH Series Brushless Coreless Motor Overview
ECH series DC brushless coreless motors adopt electronic commutation, which senses the position of permanent magnets by Hall elements and then switches the current direction in the electronic circuit, thus changing the magnetic force.
The advantage of ECH series motors is that it eliminates the loss of brushes and the interference of electric spark to electronic equipment, prolonging service life to tens of thousands of hours.
These motors offer higher speed and torque and lower noise and vibration for smooth operation and more precise control.
Product Features
This motor is free of the brush and the core while it can offer high-speed, high-torque, and low-noise and low-vibration operation by even more precise control. And the compact motor provides higher efficiency and power density.High-speed/torque
Low eddy current losses in the core and the close arrangement of the windings for high-speed and hightorque operation.
Low-noise/vibration
No cogging effect on the motor core for stable motor performance at different speeds.
Rapid response
Low motor rotor inertia, mechanical time constant less than 28ms, 10ms for certain products (100ms or more for general motors with cores).
High power density
Less weight and volume by 1/3-1/2 compared to general motors with cores.
Naming Rules
Composition
- Temperature-resistant and flame-retardant tail wire molding.
- One-piece stainless steel motor housing for high structural strength.
- Super iron core for high speed operation, low iron loss and no-load loss.
- Efficient hollow cup winding.
- Dynamically balanced rotor for high-speed and low-vibration operation.
- Ultra-quick sterilized bearings for long operating life.
- Customizable high-strength spindles.
ECH Series Brushless Coreless Motor Video
Specifications
| 13mm Motor Rated voltage: 24V |
No-load speed: 87000rpm No-load current: 600mA Rated speed: 80000rpm Rated torque: 7mNm Rated current: 3.37A Stall torque: 191mNm Stall current: 75A Maximum efficiency: 90% Inter-phase resistance: 0.32Ω Inter-phase inductance: 160uH Torque constant: 3.55mNm/A Speed constant: 3750rpm/V RPM/torque gradient: 471rpm/mNm Mechanical time constant: 1.92ms Rotor inertia: 0.42gcm2 |
|---|---|
| 13mm Motor Rated voltage: 36V |
No-load speed: 87000rpm No-load current: 450mA Rated speed: 80000rpm Rated torque: 7mNm Rated current: 2.31A Stall torque: 202mNm Stall current: 52.9A Maximum efficiency: 90% Inter-phase resistance: 0.68Ω Inter-phase inductance: 350uH Torque constant: 3.82mNm/A Speed constant: 2500rpm/V RPM/torque gradient: 445rpm/mNm Mechanical time constant: 1.92ms Rotor inertia: 0.42gcm2 |
| 13mm Motor Rated voltage: 48V |
No-load speed: 87000rpm No-load current: 350mA Rated speed: 80000rpm Rated torque: 7mNm Rated current: 1.4A Stall torque: 201.44mNm Stall current: 38.17A Maximum efficiency: 90% Inter-phase resistance: 1.45Ω Inter-phase inductance: 650uH Torque constant: 5.4mNm/A Speed constant: 1835rpm/V RPM/torque gradient: 437rpm/mNm Mechanical time constant: 1.92ms Rotor inertia: 0.42gcm2 |
| 10mm Motor Rated voltage: 12V |
No-load speed: 33600rpm No-load current: 65mA Rated speed: 27397rpm Rated torque (maximum continuous torque): 2.28mNm Rated current (maximum continuous current): 0.74A Stall torque: 12.48mNm Stall current: 3.69A Maximum efficiency: 76.4% Inter-phase resistance: 3.25Ω Inter-phase inductance: 6.35mH Torque constant: 3.38mNm/A Speed constant: 2825rpm/V RPM/torque gradient: 2716rpm/mNm Mechanical time constant: 2.2ms Rotor inertia: 0.07gcm2 |
| 10mm Motor Rated voltage: 24V |
No-load speed: 33600rpm No-load current: 50mA Rated speed: 28170rpm Rated torque (maximum continuous torque): 2.40mNm Rated current (maximum continuous current): 0.40A Stall torque: 14.88mNm Stall current: 2.18A Maximum efficiency: 78.2% Inter-phase resistance: 11Ω Inter-phase inductance: 9.2mH Torque constant: 6.82mNm/A Speed constant: 1400rpm/V RPM/torque gradient: 2258rpm/mNm Mechanical time constant: 2.2ms Rotor inertia: 0.07gcm2 |
| 16mm Motor Rated voltage: 48V |
No-load speed: 68000rpm No-load current: 500mA Rated speed: 60000rpm Rated torque: 14mNm Rated current: 2.20A Stall torque: 390mNm Stall current: 55A Maximum efficiency: 88% Inter-phase resistance: 0.2Ω Inter-phase inductance: 90uH Torque constant: 7mNm/A Speed constant: 1333rpm/V RPM/torque gradient: 164rpm/mNm Mechanical time constant: 1.65ms Rotor inertia: 0.952gcm2 |
| 13mm Motor | Housing-Ambient thermal resistance: 22.13K/W Winding- Housing thermal resistance: 1.92K/W Winding thermal time constant: 2.62S Motor thermal time constant: 502S Working temperature: -40~135℃ Maximum winding temperature: 155℃ |
|---|---|
| 10mm Motor | Housing-Ambient thermal resistance: 42.0K/W Winding- Housing thermal resistance: 7.0K/W Winding thermal time constant: 5.0S Motor thermal time constant: 155.0S Working temperature: -40~105℃ Maximum winding temperature: 155℃ |
| 16mm Motor | Housing-Ambient thermal resistance: 13.7K/W Winding- Housing thermal resistance: 0.6K/W Winding thermal time constant: 1.3S Motor thermal time constant: 490S Working temperature: -40～135℃ Maximum winding temperature: 155℃ |
Downloads
| File Name | Type | Language | File Type | Update | Download |
|---|---|---|---|---|---|
| ECH Series Brushless Coreless Motor Catalog | Catalog | English | 2024-10-30 | 3.04MB |
