VCS-156H Series Monocrystalline Bifacial Solar Panel
- 16BB Half Cell Technology.
- Significantly reduce the risk of hot spots.
- Lower electricity cost.
- Excellent anti PID performance.
- IP68 junction box.
Catalogue
Contact support
EmailVCS-156H Series 605-630W Monocrystalline Bifacial Solar Panel Overview
These monocrystalline bifacial solar panels are known for their high energy conversion efficiency, VCS-156H monocrystalline solar panel typically ranging from 605 to 630 watts. This means they can generate a substantial amount of electricity from sunlight, making them suitable for various applications.
Features of VCS-156H Series 605-630W Monocrystalline Bifacial Solar Panel
1. New circuit design, lower internal current, lower internal current Resistance loss gallium doped silicon wafer, first year attenuation＜1%, linear attenuation Minus ≤0.4%.
2. Unique circuit design significantly reduces hot spot temperature and reduces work Rate loss increases component power generation.
3. Increase power generation by 3% and reduce cost per kilowatt hour.
4. TUV SGS has twice the industry standard PID resistance(Potential induced attenuation) test (85"C/85% RH 192 hours).
5. High standard waterproof performance, effective protection against harsh environments.
Quality Assurance
Comprehensive Product and System Certification
- IEC 61215, IEC 61730
- ISO9001: 2015/Quality Management System
- ISO14001: 2015/Environmental Management Systems
- ISO45001: 2018/Occupational Health and Safety Management
- System Certification
Applications for VCS-156H Series 605-630W Monocrystalline Bifacial Solar Panel
The VCS-156H series 605-630W monocrystalline bifacial solar panels are suitable for a wide range of applications, including residential rooftop installations, commercial solar projects, and utility-scale solar farms.
Specifications
| VCS-156H-605-D | Maximum rated power(W): 605 Maximum power voltage (V): 44.66 Maximum power current (A): 13.55 Open circuit voltage(V): 53.86 Short circuit current(A): 14.19 Component efficiency(%): 21.64 |
|---|---|
| VCS-156H-610-D | Maximum rated power(W): 610 Maximum power voltage (V): 44.78 Maximum power current (A): 13.62 Open circuit voltage(V): 53.98 Short circuit current(A): 14.26 Component efficiency(%): 21.82 |
| VCS-156H-615-D | Maximum rated power(W): 615 Maximum power voltage (V): 44.90 Maximum power current (A): 13.70 Open circuit voltage(V): 54.10 Short circuit current(A): 14.33 Component efficiency(%): 22.00 |
| VCS-156H-620-D | Maximum rated power(W): 620 Maximum power voltage (V): 45.02 Maximum power current (A): 13.77 Open circuit voltage(V): 54.22 Short circuit current(A): 14.40 Component efficiency(%): 22.18 |
| VCS-156H-625-D | Maximum rated power(W): 625 Maximum power voltage (V): 45.14 Maximum power current (A): 13.85 Open circuit voltage(V): 54.34 Short circuit current(A): 14.47 Component efficiency(%): 22.36 |
| VCS-156H-630-D | Maximum rated power(W): 630 Maximum power voltage (V): 45.26 Maximum power current (A): 13.92 Open circuit voltage(V): 54.46 Short circuit current(A): 14.54 Component efficiency(%): 22.54 |
| VCS-156H-605-D | Maximum rated power(W): 461 Maximum power voltage (V): 42.30 Maximum power current (A): 10.89 Open circuit voltage(V): 51.00 Short circuit current(A): 11.44 |
|---|---|
| VCS-156H-610-D | Maximum rated power(W): 464.5 Maximum power voltage (V): 42.50 Maximum power current (A): 10.93 Open circuit voltage(V): 51.20 Short circuit current(A): 11.50 |
| VCS-156H-615-D | Maximum rated power(W): 468.4 Maximum power voltage (V): 42.60 Maximum power current (A): 10.99 Open circuit voltage(V): 51.40 Short circuit current(A): 11.56 |
| VCS-156H-620-D | Maximum rated power(W): 471.7 Maximum power voltage (V): 42.70 Maximum power current (A): 11.04 Open circuit voltage(V): 51.50 Short circuit current(A): 11.61 |
| VCS-156H-625-D | Maximum rated power(W): 475.9 Maximum power voltage (V): 42.90 Maximum power current (A): 11.10 Open circuit voltage(V): 51.60 Short circuit current(A): 11.67 |
| VCS-156H-630-D | Maximum rated power(W): 479.5 Maximum power voltage (V): 43.00 Maximum power current (A): 11.15 Open circuit voltage(V): 51.70 Short circuit current(A): 11.72 |
| Maximum Power temperature coefficient(Pmax) | -0.34%℃ |
|---|---|
| Open Circuit voltage temperature coefficient(Voc) | -0.26%℃ |
| Short Circuit voltage temperature coefficient(Isc) | -0.05%℃ |
| Working temperature | -40~+85℃ |
| Rated operating cell temperature | 42±2℃ |
| Specifications | N-TOPCON 182×182mm |
|---|---|
| Battery arrangement | N-TOPCON 156[2✖(6✖13)] |
| Component dimensions | 2465✖1134✖30mm |
| Component weight | 34.6kg |
| Component panel | 2mm-2mm semi tempered glass |
| Component border | Anodic oxygen film aluminum alloy |
| Junction box | IP68, 3 Diodes |
| Wireway | 4.0 square millimeters(IEC) |
| Wire length(including connectors) | 300mm, wire length can be customized |
| Connector | KSW-CN01 |
